Planet SGS-6341-24T4X User Manual

15-149
15.26 show mls qos vlan
Command:
show mls qos vlan <v-id>
Parameters:
v-id: the ranging from 1 to 4094.
Default:
None.
Examples:
Switch#show mls qos vlan 1
Vlan 1:
Attached Policy Map for Ingress: 1
Classmap classified in-profile out-profile (in packets)
1 NA NA NA
Switch(config)#show mls qos vlan 7
Vlan 7:
Attached Policy Map for Ingress: 7
Classmap classified in-profile out-profile (in packets)
7 0 0 0
15.27 show mls qos aggregate-policy
Command:
show mls qos aggregate-policy [<aggregate-policy-name>]
Function:
Show aggregate-policy information of QoS.
Parameters:
<aggregate-policy-name> the aggregate-policy name
Command mode:
Admin and Configuration Mode.
Usage Guide:
Show all or the specified aggregate-policy configuration.
Example:
Switch(config)#show mls qos aggregate-policy a2
aggregate policy a2 10 10 10 exceed-action drop

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
