Planet SGS-6341-24T4X User Manual

14-120
Switch(config)#spanning-tree mst configuration
Switch(Config-Mstp-Region)#show mst-pending
Name switch
Revision 0
Instance Vlans Mapped
----------------------------------
00 1-29, 31-39, 41-4093
03 30
04 40
05 4094
----------------------------------
Switch(Config-Mstp-Region)#
14.2.3 show spanning-tree
Command:
show spanning-tree [mst [<instance-id>]] [interface <interface-list>] [detail]
Function:
Display the MSTP Information.
Parameter:
<interface-list> sets interface list; <instance-id> sets the instance ID. The valid range is from 0 to
64; detail sets the detailed spanning-tree information.
Command mode:
Admin and Configuration Mode
Usage Guide:
This command can display the MSTP information of the instances in the current bridge.
Example:
Display the bridge MSTP.
Switch#sh spanning-tree
-- MSTP Bridge Config Info --
Standard : IEEE 802.1s
Bridge MAC : 00: 03: 0f: 01: 0e: 30
Bridge Times : Max Age 20, Hello Time 2, Forward Delay 15
Force Version: 3

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
