Planet SGS-6341-24T4X User Manual

31-115
Switch(config-route-map)#match as-path 60
31.5 match community
Command:
match community <community-list-name | community-list-num> [exact-match]
no match community [<community-list-name | community-list-num> [exact-match]]
Function:
Configure the community attributes of BGP routing messages. The “no match community
[<community-list-name | community-list-num > [exact-match]]” command deletes this
configuration.
Parameter:
<community-list-name > is the name of the community-list, <community-list-num > is the
community-list sequence number, ranging between 1～99 (Standard ACL) or 100～199 (Extended
ACL), [exact-match] means precise matching.
Command Mode:
route-map mode
Usage Guide:
This command matches the community attributes of the BGP routing message following the rules
specified in the community list. If the matching succeeded, then the “permit” or “deny” action in the
route-map is performed.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#match community 100 exact-match
31.6 match interface
Command:
match interface <interface-name >
no match interface [<interface-name >]
Function:
Configure to match the interfaces. The “no match interface [<interface-name >]“deletes this
configuration.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
