Planet SGS-6341-24T4X User Manual

9-14
9.2 interface port-channel
Command:
interface port-channel <port-channel-number>
Function:
Enters the port channel configuration mode
Command mode:
Global Mode
Usage Guide:
On entering aggregated port mode, configuration to GVRP or spanning tree modules will apply to
aggregated ports; if the aggregated port does not exist (i.e., ports have not been aggregated), an
error message will be displayed and configuration will be saved and will be restored until the ports
are aggregated. Note such restoration will be performed only once, if an aggregated group is
ungrouped and aggregated again, the initial user configuration will not be restored. If it is
configuration for modules, such as shutdown configuration, then the configuration to current port will
apply to all member ports in the corresponding port group.
Example:
Entering configuration mode for port-channel 1.
Switch(config)#interface port-channel 1
Switch(Config-If-Port-Channel1)#
9.3 lacp port-priority
Command:
lacp port-priority <port-priority>
no lacp port-priority
Function:
Set the port priority of LACP protocol.
Parameters:
<port-priority>: the port priority of LACP protocol, the range from 0 to 65535.
Command mode:
Port Mode.
Default:
The default priority is 32768 by system.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
