Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-93
user name at v3.
Usage Guide:
The Community character string configured in this command is the default community string of the RMON event
group. If the RMON event group has no community character string configured, the community character string
configured in this command will be applied when sending the Trap of RMON, and if the community character string is
configured, its configuration will be applied when sending the RMON trap. This command allows configuration the
IPv4 or IPv6 address of the network manage station receiving the SNMP Trap message, but configure the version
number as v1 and v2c of the IPv4 and IPv6 address are less than 8 in all.
Example:
Configure an IP address to receive Trap
Switch(config)#snmp-server host 1.1.1.5 v1 usertrap
Delete a Trap receiving IPv6 address
Switch(config)#no snmp-server host 2001:1:2:3::1 v1 usertrap
1.4.18 snmp-server securityip
Command:
snmp-server securityip {<ipv4-address> | <ipv6-address>}
no snmp-server securityip {<ipv4-address> | <ipv6-address>}
Function:
Configure to permit to access security IPv4 or IPv6 address of the switch NMS administration station; the no
command deletes configured security IPv4 or IPv6 address.
Command Mode:
Global Mode.
Parameter:
<ipv4-address> is NMS security IPv4 address, point separated decimal format.
<ipv6-address> is NMS security IPv6 address, colon separated hex format.
Usage Guide:
It is only the consistency between NMS administration station IPv4 or IPv6 address and security IPv4 or IPv6
address configured by the command, so it send SNMP packet could be processed by switch, the command only
applies to SNMP. Allows configuration the IPv4 or IPv6 address of the network manage station receiving the SNMP
Trap message, but the IP addresses are less than 6 in all.
Example:
Configure security IP address of NMS administration station
Switch(config)#snmp-server securityip 1.1.1.5
Delete security IPv6 address
Switch(config)#no snmp-server securityip 2001::1

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
