11.29 show ethernet-oam loopback status
Command:
show ethernet-oam loopback status [interface {ethernet |} <IFNAME>]
Function:
Show OAM loopback status of specified or all ports.
Parameter:
<IFNAME>, the port that OAM loopback status needs to be shown, OAM loopback status for all
ports will be shown if this parameter is not specified.
Command Mode:
Admin mode
Example:
Show OAM loopback status of all ports.
Switch(config)#show ethernet-oam loopback status
OAM Loopback Status：
ethernet 1/0/1：disable
ethernet 1/0/2：loopback_enable_waiting
ethernet 1/0/3：loopback_disable_waiting
ethernet 1/0/4：loopback_control
ethernet 1/0/5：loopback_underControl
Field
Description
Disable
OAM loopback support is not enabled
loopback_enable_waiting
The local side is the loopback control end with remote loopback
request sent and is waiting for the confirmation packets
loopback_disable_waiting
The local
side is the loopback control end with remote loopback
cancellation request sent and is waiting for the confirmation packets
loopback_control
The local side is the loopback control end and is in the loopback
process
loopback_undercontrol
The local s
ide is the loopback control end and is in the loopback
process
no_loopback
OAM loopback support is enabled but no loopback request is received
