Planet SGS-6341-24T4X User Manual

45-66
ff1e::1:3 Vlan1 00:00:16 00:03:14
Switch#
Displayed Information
Explanations
Group Address
Multicast group IP address
Interface
The interface of multicast group
Uptime
The existing time of the multicast group
Expires
The left time to overtime
45.7.16 show ipv6 mld interface
Command:
show ipv6 mld interface [<ifname>]
Function:
Display the relevant MLD information of an interface.
Parameter:
<ifname> is the name of the interface. Display the MLD information of a specific interface.
Default:
Do not display
Command Mode:
Admin Mode
Example:
Display the MLD information of the Ethernet Interface vlan1
Switch#show ipv6 mld interface Vlan1
Interface Vlan1(2003)
Index 2003
Internet address is fe80::203:fff:fe01:e4a
MLD querier
MLD query interval is 100 seconds
MLD querier timeout is 205 seconds
MLD max query response time is 10 seconds
Last member query response interval is 1000 ms
Group membership interval is 210 seconds
MLD is enabled on interface
45.7.17 show ipv6 mld join-group

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
