Planet SGS-6341-24T4X User Manual

12-69
12.1.33 switchport trunk native vlan
Command:
switchport trunk native vlan <vlan-id>
no switchport trunk native vlan
Function:
Set the PVID for Trunk port; the “no switchport trunk native vlan” command restores the default
setting.
Parameter:
<vlan-id> is the PVID for Trunk port.
Command mode:
Port Mode.
Default:
The default PVID of Trunk port is 1.
Usage Guide:
PVID concept is defined in 802.1Q. PVID in Trunk port is used to tag untagged frames. When a
untagged frame enters a Trunk port, the port will tag the untagged frame with the native PVID set
with this commands for VLAN forwarding.
Example:
Set the native VLAN for a Trunk port to 100.
Switch(config)#interface ethernet 1/0/5
Switch(Config-If-Ethernet1/0/5)#switchport mode trunk
Switch(Config-If-Ethernet1/0/5)#switchport trunk native vlan 100
Switch(Config-If-Ethernet1/0/5)#exit
12.1.34 vlan
Command:
vlan WORD
no vlan WORD
Function:
Create VLANs and enter VLAN configuration mode. If using ';' and '-' connect with multi-VLANs,
then only create these VLANs. If only existing VLAN, then enter VLAN configuration mode; if the
VLAN is not exist, then create VLAN and enter VLAN configuration mode. In VLAN Mode, the user
can set VLAN name and assign the switch ports to the VLAN. The no command deletes specified

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
