Planet SGS-6341-24T4X User Manual

68-10
ip-address: IPv4 address of time server
ipv6-address: IPv6 address of time server
source: Specify the interface of the source address
vlan: Configure the virtual LAN
vlan no: Virtual LAN number, ranging from 1 to 4094
loopback: Configure loopback interface
loopback no: Loopback identifier, ranging from 1 to 1024
version: Configure the version for the server
version_no: Version number, ranging from 1 to 4, the default is 4
Default:
Do not configure the time server.
Command Mode:
Global mode
Example:
Configure the time server address as 1.1.1.1, specify the interface of the source address as vlan1:
Switch(config)#sntp server 1.1.1.1 source vlan 1
Delete the time server that the address is 1.1.1.1, the interface of the specified source address is
vlan1:
Switch(config)#no sntp server 1.1.1.1 source vlan 1
68.5 show sntp
Command:
show sntp
Function:
Displays current SNTP client configuration and server status.
Command Mode:
Admin and Configuration Mode.
Example:
Displaying current SNTP configuration.
Switch#show sntp
SNTP server Version Last Receive
2.1.0.2 1 6

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
