Planet SGS-6341-24T4X User Manual

12-65
port, traffic of VLANs not included are prohibited. The difference between tag and untag mode by
setting allowed vlan: set VLAN to untag mode, the frame sent via hybrid port without VLAN tag; set
VLAN to tag mode, the frame sent via hybrid port with corresponding VLAN tag. The same VLAN
can not be allowed with tag and untag mode by a Hybrid port at the same time. If configure the tag
(or untag) allowed VLAN to untag (or tag) allowed VLAN, the last configuration will cover the before.
Example:
Set hybrid port allowed vlan 1, 3, 5-20 with untag mode and allow vlan 100; 300; 500-2000 with tag
mode.
Switch(config)#interface ethernet 1/0/5
Switch(Config-If-Ethernet1/0/5)#switchport mode hybrid
Switch(Config-If-Ethernet1/0/5)#switchport hybrid allowed vlan 1;3;5-20 untag
Switch(Config-If-Ethernet1/0/5)#switchport hybrid allowed vlan 100; 300; 500-2000 tag
Switch(Config-If-Ethernet1/0/5)#exit
12.1.28 switchport hybrid native vlan
Command:
switchport hybrid native vlan <vlan-id>
no switchport hybrid native vlan
Function:
Set the PVID for Hybrid port; the “no switchport hybrid native vlan” command restores the default
setting.
Parameter:
<vlan-id> is the PVID of Hybrid port.
Command mode:
Port Mode.
Default:
The default PVID of Hybrid port is 1.
Usage Guide:
When an untagged frame enters a Hybrid port, it will be added a tag of the native PVID which is set
by this command, and is forwarded to the native VLAN.
Example:
Set the native vlan to 100 for a Hybrid port.
Switch(config)#interface ethernet 1/0/5
Switch(Config-If-Ethernet1/0/5)#switchport mode hybrid
Switch(Config-If-Ethernet1/0/5)#switchport hybrid native vlan 100
Switch(Config-If-Ethernet1/0/5)#exit

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
