65-6
throughput of the interfaces to be mirrored. If the destination of a session is removed, the mirror
path configured in the session will be removed at the same time. And if the destination interface is
reconfigured, the interface path will be recovered. To be mentioned, the flow mirror can only be
recovered after the destination of the interface is re-configured.
Example:
Configure interface 1/0/7 as the destination of the mirror.
Switch(config)#monitor session 1 destination interface ethernet 1/0/7
65.4 show monitor
Command:
show monitor
Function:
To display information about the source and destination ports of all the mirror sessions.
Command Mode:
Admin Mode
Usage Guide:
This command is used to display the source and destination ports for the configured mirror sessions.
For port mirroring and flow mirroring, the mirror mode of the source can be displayed. For MAC
mirroring, MAC mirror configuration will be displayed for the supported switch cards.
Example:
Switch#show monitor

Table of Contents

Other manuals for Planet SGS-6341-24T4X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet SGS-6341-24T4X and is the answer not in the manual?

Planet SGS-6341-24T4X Specifications

General IconGeneral
Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Form factor1U
CertificationFCC Part 15 Class A, CE
Product colorBlack
Console portRJ-45
SFP+ module slots quantity4
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity24
Routing entries128
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresStacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Flash memory16 MB
Internal memory512 MB
Processor frequency400 MHz
AuthenticationMAC-based authentication, Port-based authentication
Security algorithmsSNMPv3, SSH, SSL/TLS
Throughput95.24 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply included-
Power consumption (max)19.9 W
Heat dissipation67.91 BTU/h
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width440 mm
Height43.6 mm
Weight3170 g
