SGS-6341 Series Command Guide
4-134
Example:
Set the rate-violation of port 8-10 (GB ports) of the switch as 10000pps and the port recovery time as 1200 seconds.
Switch(config)#interface ethernet 1/0/8-10
Switch(Config-Port-Range)#rate-violation 10000 recovery 1200
4.1.14 show interface
Command:
show interface [ethernet <interface-number> | port-channel <port-channel-number> | loopback
<loopback-id> | vlan <vlan-id> | tunnel <tunnel-id> | <interface-name> ] [detail]
show interface ethernet status
show interface ethernet counter {packet | rate}
Function:
Show information of layer 3 or layer 2 port on the switch
Parameter:
<vlan-id> is the VLAN interface number, the value range from 1 to 4094.
<tunnel-number> is the tunnel number, the value range from 1 to 50.
<loopback-id> is the loop back number, the value range from 1 to 1024.
<interface-number> is the port number of the Ethernet, status show important information of all the layer 2 ports.
counter {packet | rate} show package number or rate statistics of all layer 2 ports.
<port-channel-number> is the number of the aggregation interface,
<interface-name> is the name of the interface such as port-channel1.
[detail] show the detail of the port.
Command Mode:
Admin and Configuration Mode.
Default:
Information not displayed by default
Usage Guide:
While for vlan interfaces, the port MAC address, IP address and the statistic state of the data packet will be shown; for
tunnel port, this command will show tunnel interface state and the statistic state of control layer receives/sends tunnel
data packet, about the statistic data of physics interface receiving/sending data packet, please refer to show interface
ethernet command; for loopback port, this command will show the interface statistic state of IP address and
receiving/sending data packet; As for Ethernet port, this command will show port speed rate, duplex mode, flow
control switch state, broadcast storm restrain of the port and the statistic state of the data packets; for aggregated port,
port speed rate, duplex mode, flow control switch state, broadcast storm restrain of the port and the statistic state of
the data packets will be displayed. The information of all ports on the switch will be shown if no port is specified.
Using [detail] to show the detail information for ethernet port and port-channel port, the information is related with the
type of switch, board card.
