Planet SGS-6341-24T4X User Manual

11-28
Usage Guide:
During the specific detection period, errored frame period event is induced if the number of errored
frame is larger than or equal to the low threshold and the device notifies the peer by event
notification OAMPDU. Note that the low threshold should not be larger than the high threshold.
Example:
Configure the low threshold of errored frame period event on port 1/0/4 to 100.
Switch(Config-If-Ethernet1/0/4)#ethernet-oam errored-frame-period threshold low 100
11.12 ethernet-oam errored-frame-period window
Command:
ethernet-oam errored-frame-period window <seconds>
no ethernet-oam errored-frame-period window
Function:
Configure the detection period of errored frame period event, no command restores the default
value.
Parameter:
<seconds>, the detection period value of errored frame period event, ranging from 1 to 60s.
Default:
1
Command Mode:
Port mode
Usage Guide:
Detect errored frame of the port after the time of specific detection period. If the number of errored
frame is larger than or equal to the threshold, corresponding event is induced and the device
notifies the peer through OAMPDU. When sending the packets, the maximum number of frames is
filled as the value of window in errored frame period event. The conversion rule is maximum number
of frames= interface bandwidth×detection period of errored frame period event(s)÷(64×8), of which
the detection period is the number of seconds in window of the configuration.
Example:
Configure the detection period of errored frame period event on port 1/0/4 to 10s.
Switch(Config-If-Ethernet1/0/4)#ethernet-oam errored-frame-period window 10

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
