Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-127
4.1.3 clear counters interface
Command:
clear counters interface [{ethernet <interface-list> | vlan <vlan-id> | port-channel <port-channel-number> |
<interface-name>}]
Function:
Clears the statistics of the specified port.
Parameters:
<interface-list> stands for the Ethernet port number;
<vlan-id> stands for the VLAN interface number;
<port-channel-number> for trunk interface number;
<interface-name> for interface name, such as port-channel 1.
Command mode:
Admin Mode.
Default:
Port statistics are not cleared by default.
Usage Guide:
If no port is specified, then statistics of all ports will be cleared.
Example:
Clearing the statistics for Ethernet port1/0/1.
Switch#clear counters interface ethernet 1/0/1
4.1.4 flow control
Command:
flow control
no flow control
Function:
Enables the flow control function for the port: the “no flow control” command disables the flow control function for
the port.
Command mode:
Port Mode.
Default:
Port flow control is disabled by default.
Usage Guide:
After the flow control function is enabled, the port will notify the sending device to slow down the sending speed to
prevent packet loss when traffic received exceeds the capacity of port cache. Ports support IEEE802.3X flow control;
the ports work in half-duplex mode, supporting back-pressure flow control. If flow control results in serious HOL, the

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
