Page #230 background imageLoading...
Page #230 background image
12-76
12.2.4 mac-vlan vlan
Command:
mac-vlan vlan <vlan-id>
no mac-vlan vlan <vlan-id>
Function:
Configure the specified VLAN to MAC VLAN; the “no mac-vlan vlan <vlan-id>command cancels
the MAC VLAN configuration of this VLAN.
Parameter:
<vlan-id> is the number of the specified VLAN.
Command Mode:
Global Mode.
Default:
No MAC VLAN is configured by default.
Usage Guide:
Set specified VLAN for MAC VLAN.
Example:
Set VLAN100 to MAC VLAN.
Switch#config
Switch(config)#mac-vlan vlan 100
12.2.5 protocol-vlan
Command:
protocol-vlan mode {ethernetii etype <etype-id> | llc {dsap <dsap-id> ssap <ssap-id>} | snap
etype <etype-id>} vlan <vlan-id> priority <priority-id>
no protocol-vlan {mode {ethernetii etype <etype-id> | llc {dsap <dsap-id> ssap <ssap-id>} |
snap etype <etype-id>} | all}
Function:
Add the correspondence between the protocol and the VLAN namely specify the protocol to join
specified VLAN. The “no” form of this command deletes all/the correspondence.
Parameter:
mode is the encapsulate type of the configuration which is ethernetii, llc, snap; the encapsulate type
of the ethernetii is EthernetII;
etype-id is the type of the packet protocol, with a valid range of 1536~65535;
llc is LLC encapsulate format;
dsap-id is the access point of the destination service, the valid range is 0~255;
