Planet SGS-6341-24T4X User Manual

45-46
self-rp-address:
The configured self-rp-address.
anycast-rp address:
The configured anycast-rp-address.
other rp unicast rp address:
The configured other RP communication addresses in
accordance with the above anycast-rp-address.
other rp unicast rp address:
The configured other RP communication addresses in
accordance with the above anycast-rp-address.
anycast-rp address:
The configured anycast-rp-address*.
other rp unicast rp address:
The configured other RP communication addresses in
accordance with the above anycast-rp-address.
45.5 Commands for PIM-SSM6
45.5.1 ipv6 pim ssm
Command:
ipv6 pim ssm {default|range <access-list-name >}
no ipv6 pim ssm
Function:
Configure the range of pim ssm multicast address. The “no ipv6 pim ssm” command deletes
configured pim ssm multicast group.
Parameter:
default: indicates the default range of pim ssm multicast group is ff3x::/32.
<access-list-number > is the name of applying access-list.
Default:
Do not configure the range of pim ssm group address
Command Mode:
Global Mode
Usage Guide:
1. Only this command is configured, pim ssm can be available.
2. Before configuring this command, make sure ipv6 pim multicasting succeed.
3. Access-list only can use the lists created by ipv6 access-list.
4. Users can execute this command first and then configure the corresponding acl; or delete
corresponding acl in the bondage. After the bondage, only command no ipv6 pim ssm can release
the bondage.
5. If ssm is needed, this command should be configured at the related edge route. For example, the
local switch with igmp(must) and multicast source DR or RP(at least one of the two) configure this
command, the middle switch need only enable PIM-SM.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
