Planet SGS-6341-24T4X User Manual

19-200
There is no IPv4 address of tunnel nexthop.
Usage Guide:
This command is for ISATAP tunnel, other tunnels won’t check the configuration of nexthop. Notice:
IPv4 address of ISATAP tunnel nexthop and IPv4 address of tunnel source should be in same
segment.
Example:
Configure tunnel next hop 178.99.156.8.
Switch(Config-if-Tunnel1)#tunnel source 178.99.156.7
Switch(Config-if-Tunnel1)#tunnel nexthop 178.99.156.8
Switch(Config-if-Tunnel1)#tunnel mode ipv6ip isatap
19.2.41 tunnel mode
Command:
tunnel mode [[gre] | ipv6ip [6to4 | isatap]]
no tunnel mode
Function:
Configure Tunnel Mode.
Parameter:
gre is GRE tunnel.
Command Mode:
Tunnel Configuration Mode.
Usage Guide:
In configuring tunnel mode, only specifying ipv6ip indicates configuring tunnel. Ipv6ip 6to4 indicates
it is 6to4 tunnel, ipv6ip isatap indicates it is ISATAP tunnel.
Example:
Configure tunnel mode.
1、Switch(Config-if-Tunnel1)#tunnel mode ipv6ip
2、Switch(Config-if-Tunnel1)#tunnel mode ipv6ip 6to4
3、Switch(Config-if-Tunnel1)#tunnel mode ipv6ip isatap

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
