Planet SGS-6341-24T4X User Manual

19-199
Example:
Configure tunnel source IPv4 address 202.89.176.6.
Switch(Config-if-Tunnel1)#tunnel source 202.89.176.6
19.2.39 tunnel destination
Command: .
tunnel destination <ipaddress | ipv6address>
no tunnel destination
Function:
Configure the IPv4/IPv6 address of the tunnel destination.
Parameter:
<ipaddress> is the IPv4 address of tunnel destination, <ipv6address> is the IPv6 address of
tunnel destination.
Command Mode:
Tunnel Configuration Mode.
Default Situation:
There is no IPv4/IPv6 address of tunnel destination.
Usage Guide:
This command is used to configure the IPv4/IPv6 address of tunnel destination.
Example:
Configure tunnel destination 203.78.120.5.
Switch(Config-if-Tunnel1)#tunnel destination 203.78.120.5
19.2.40 tunnel nexthop
Command:
tunnel nexthop <ipaddress>
no tunnel nexthop
Function:
Configure tunnel next hop.
Parameter:
<ipaddress> is the ipv4 address of tunnel next hop.
Command Mode:
Tunnel Configuration Mode.
Default Situation:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
