Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
3-117
Parameter:
key：all keys in one cluster should be the same, no longer than 16 characters.
vid：vlan id of the cluster, whose range is 1-4094.
Command mode:
Global Mode
Default:
Cluster function is disabled by default, key: NULL(\0) vid：1.
Instructions:
This command enables cluster function. Cluster function has to be enabled before implementing any other cluster
commands. The “no cluster run” disables cluster function. It is recommended that users allocate an exclusive vlan
for cluster（such as vlan100）
Note：Routing protocols should be disabled on the layer-3 interface where cluster vlan locates to avoid broadcasting
private route of the cluster.
Example:
Disable cluster function in the local switch.
Switch (config)#no cluster run
3.11 cluster update member
Command:
cluster update member <member-id> <src-url> <dst-filename> [ascii | binary]
Function:
Remotely upgrade member switches from the commander switch.
Parameters:
member-id：ranging from 1 to 128. Use hyphen “-” or semicolon “；” to specify more than one member;
src-url：the location of source files to be copied;
dst-filename：the specified filename for saving the file in the switch flash;
ascii means that the file transmission follows ASCII standard; binary means that the file transmission follows binary
standard, which is de default mode.
when src-url is a FTP address, its form will be: ftp://<username>:<password>@<ipadress>/<filename>，in which
<username> is the FTP username <password> is the FTP password <ipadress> is the IP address of the FTP
server,<filename> is the name of the file to be downloaded via FTP.
when src-url is a TFTP address, its form will be: tftp://<ipadress>/<filename>，in which <ipadress>is the IP address of
the TFTP server <filename> is the name of the file to be downloaded via.
Special keywords used in filename:
Keywords
source or destination address
startup-config
start the configuration file
nos.img
system file

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
