Planet SGS-6341-24T4X User Manual

47-28
IP Ingress access-list used is 100, traffic-statistics Disable.
interface name: Ethernet1/0/2
IP Ingress access-list used is 1, packet(s) number is 11110.
Displayed information
Explanation
interface name: Ethernet 1/0/1
Tying situation on port Ethernet1/0/1
IP Ingress access-list used is 100
No. 100 numeric expansion ACL tied to entrance of port
Ethernet1/0/1
packet(s) number is 11110
Number of packets matching this ACL rule
47.26 show firewall
Command:
show firewall
Functions:
Reveal configuration information of packet filtering functions.
Command Mode:
Admin and Configuration Mode.
Examples:
Switch#show firewall
Firewall status: Enable
Displayed information
Explanation
fire wall is enable
Packet filtering function enabled
47.27 show ipv6 access-lists
Command:
show ipv6 access-lists [<num>|<acl-name>]
Function:
Show the configured IPv6 access control list.
Parameter:
<num> is the number of specific access control list, the valid range is 500～699, amongst 500～599
is digit standard IPv6 ACL number, 600～699 is the digit extended IPv6 ACL number; <acl-name> is
the nomenclature character string of a specific access control list, lengthening within 1～16.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
