Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-129
Command mode:
Port Mode.
Default:
Loopback test is disabled in Ethernet port by default.
Usage Guide:
Loopback test can be used to verify the Ethernet ports are working normally. After loopback has been enabled, the
port will assume a connection established to itself, and all traffic sent from the port will be received at the very same
port.
Example:
Enabling loopback test in Ethernet ports 1/0/1-8.
Switch(config)#interface ethernet 1/0/1-8
Switch(Config-If-Port-Range)#loopback
4.1.7 mdi
Command:
mdi { auto | across | normal }
no mdi
Function:
Sets the cable types supported by the Ethernet port; the “no mdi” command sets the cable type to auto-identification.
This command is not supported on combo ports and fiber ports.
Parameters:
auto indicates auto identification of cable types;
across indicates crossover cable support only;
normal indicates straight-through cable support only.
Command mode:
Port Mode.
Default:
Port cable type is set to auto-identification by default.
Usage Guide:
Auto-identification is recommended. Generally, straight-through cable is used for switch-PC connection and
crossover cable is used for switch-switch connection.
Example:
Setting the cable type support of Ethernet ports 1/0/1-8 to straight-through cable only.
Switch(config)#interface ethernet 1/0/1-8
Switch(Config-Port-Range)#mdi normal

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
