Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
3-116
members to manually added ones to keep them.
Command Mode:
Global Mode.
Usage Guide:
Execute this command on a switch to change automatically added members to manually added ones.
Example:
change automatically added members to manually added ones.
Switch(config)#cluster member auto-to-user
3.9 cluster reset member
Command:
cluster reset member [id <member-id> | mac-address <mac-addr>]
Function:
In the commander switch, this command can be used to reset the member switch.
Parameter:
member-id: ranging from 1 to 128. Use hyphen “-” or semicolon “;” to specify more than one member; if no value is
provided, it means to reboot all member switches.
Default:
Boot all member switches.
Command mode:
Admin Mode.
Instructions:
In the commander switch, users can use this command to reset a member switch. If this command is executed in a
non-commander switch, an error will be displayed.
Example:
In the commander switch, reset the member switch 1.
Switch#cluster reset member 1
3.10 cluster run
Command:
cluster run [key <WORD>][ vid <VID>]
no cluster run
Function:
Enable cluster function; the “no cluster run” command disables cluster function.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
