Planet SGS-6341-24T4X User Manual

37-317
Switch(config-router)#neighbor 10.1.1.68 route-map map1 in
Switch(config-router)#address-family vpnv4 unicast
Switch(config-router-af)#neighbor 10.1.1.68 activate
Switch(config-router-af)#exit-address-family
View the route message after refresh:
Switch#show ip bgp vpnv4 all
Network Next Hop Metric LocPrf Weight Path
Route Distinguisher: 100:10 (Default for VRF DC1)
*> 11.1.1.0/24 11.1.1.64 0 0 200 ?
*>i15.1.1.0/24 10.1.1.250 0 100 655 200 ?
*> 20.1.1.0/24 11.1.1.64 0 0 200 ?
*>i100.1.1.0/24 10.1.1.250 0 100 655 200 ?
Route Distinguisher: 100:10
*>i15.1.1.0/24 10.1.1.68 0 100 0 200 ?
*>i100.1.1.0/24 10.1.1.68 0 100 0 200 ?
We can see that the nexthop 10.1.1.68 of the VPN route is changed to 10.1.1.250 after applied with
route-map.
37.88 show ip bgp
Command:
show ip bgp [<ADDRESS-FAMILY>] [<ip-address>|<ip-address/M> [longer-prefixes]|
cidr-only]
Function:
For displaying the routing messages permitted by BGP.
Parameter:
<ADDRESS-FAMILY>: address-family such as “ipv4 unicast”
<ip-address>: IP address
<ip-address/M>: IP address and the mask
Command Mode:
Admin and configuration mode
Usage Guide:
We can display BGP routing messages by different parameters (such as address-family or IPv4
address), or a route covered by a prefix, or only the routing message don’t match the earliest IP
address-family (namely the route is not A or B or C type address.)

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
