Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-131
Usage Guide:
This command applies to 1000Base-FX interface only. The negotiation command is not available for 1000Base-TX
or 100Base-TX interface. For combo port, this command applies to the 1000Base-FX port only but has no effect on
the 1000Base-TX port. To change the negotiation mode, speed and duplex mode of 1000Base-TX port, use
speed-duplex command instead.
Example:
Port 1 of Switch1 is connected to port 1 of Switch2, the following will disable the negotiation for both ports.
Switch1(config)#interface ethernet1/0/1
Switch1(Config-If-Ethernet1/0/1)#negotiation off
Switch2(config)#interface ethernet1/0/1
Switch2(Config-If-Ethernet1/0/1)#negotiation off
4.1.10 port-rate-statistics interval
Command:
port-rate-statistics interval [<interval-value>]
Function:
Set the interval of port-rate-statistics, ranging from 5 to 600.
Parameters:
interval-value: The interval of port-rate-statistics, unit is second, ranging from 5 to 600 with the configuration step of
5.
Command mode:
Global Mode.
Default:
Only port-rate-statistics of 5 seconds and 5 minutes are displayed.
Example:
Count the interval of port-rate-statistics as 20 seconds.
Switch(config)# port-rate-statistics interval 20
4.1.11 port-scan-mode
Command:
port-scan-mode {interrupt | poll}
no port-scan-mode
Function:
Configure the scan mode of the port as “interrupt” or “poll”, the no command restores the default scan mode.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
