Planet SGS-6341-24T4X User Manual

14-108
14.1.16 spanning-tree max-hop
Command:
spanning-tree max-hop <hop-count>
no spanning-tree max-hop
Function:
Set maximum hops of BPDU in the MSTP region; the command “no spanning-tree max-hop”
restores the default setting.
Parameter:
<hop-count> sets maximum hops. The valid range is from 1 to 40.
Command mode:
Global Mode
Default:
The max hop is 20 by default.
Usage Guide:
The MSTP uses max-age to count BPDU lifetime. In addition, MSTP also uses max-hop to count
BPDU lifetime. The max-hop is degressive in the network. The BPDU has the max value when it
initiates from MSTI root bridge. Once the BPDU is received, the value of the max-hop is reduced by
1. When a port receives the BPDU with max-hop as 0, it drops this BPDU and sets itself as
designated port to send the BPDU.
Example:
Set max hop to 32.
Switch(config)#spanning-tree max-hop 32
14.1.17 spanning-tree mcheck
Command:
spanning-tree mcheck
Function:
Force the port to run in the MSTP mode.
Command mode:
Port Mode
Default:
The port is in the MSTP mode by default.
Usage Guide:
If a network which is attached to the current port is running IEEE 802.1D STP, the port converts itself
to run in STP mode. The command is used to force the port to run in the MSTP mode. But once the

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
