Command Mode:
Global Mode
Default:
ascii.
User Guide:
VLAN and port information with ASCII format, such as “Vlan1+Ethernet1/0/11”, VLAN and port
information with hexadecimal format defined as below:
1 8 0 6 VLAN Slot Module Port
1 byte 1 byte 1 byte 1 byte 2 byte 1 byte 1 byte 2 byte
Suboption
type
Length
Circuit
ID type
Length
VLAN field fills in VLAN ID. For chassis switch, Slot means slot number, for box switch, Slot is 1;
default Module is 0; Port means port number which begins from 1.
The compatible subscriber-id format with HP manufacturer defined as below:
1
2
Port
1 byte 1 byte
2 byte
Suboption
type
Length
Port means port number which begins from 1.
Example:
Set subscriber-id format of Relay Agent option82 as hexadecimal format.
Switch(config)#ip dhcp relay information option subscriber-id format hex
28.12 ip dhcp relay information policy
Command:
ip dhcp relay information policy {drop | keep | replace}
no ip dhcp relay information policy
Function:
This command is used to set the retransmitting policy of the system for the received DHCP request
message which contains option82. The drop mode means that if the message has option82, then
the system will drop it without processing; keep mode means that the system will keep the original
option82 segment in the message, and forward it to the server to process; replace mode means that

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
