Planet SGS-6341-24T4X User Manual

28-68
28.10 ip dhcp relay information option subscriber-id
Command:
ip dhcp relay information option subscriber-id {standard | <circuit-id>}
no ip dhcp relay information option subscriber-id
Function:
This command is used to set the format of option82 sub-option1(Circuit ID option) added to the
DHCP request messages from interface, standard means the standard vlan name and physical
port name format, like”Vlan2+Ethernet1/0/12”,<circuit-id> is the circuit-id contents of option82
specified by users, which is a string no longer than 64 characters. The” no ip dhcp relay
information option subscriber-id” command will set the format of added option82 sub-option1
(Circuit ID option) as standard format.
Command Mode:
Interface configuration mode.
Default:
The system uses the standard format to set the circuit-id of option 82 by default.
User Guide:
Because the option 82 information added for the switch should cooperate with the third party DHCP
server, if the standard circuit-id format of the switch cannot satisfy the server’s request, this method
will be provided for users to specify the contents of circuit-id according to the situation of the server.
Example:
Set the sub-option circuit-id of DHCP option82 as foobar.
Switch(config-if-vlan1)#ip dhcp relay information option subscriber-id foobar
28.11 ip dhcp relay information option subscriber-id
format
Command:
ip dhcp relay information option subscriber-id format {hex | acsii | vs-hp}
Function:
Set subscriber-id format of Relay Agent option82.
Parameters:
hex means that subscriber-id is VLAN and port information with hexadecimal format, acsii means
that subscriber-id is VLAN and port information with ACSII format. vs-hp means that subscriber-id is
compatible with the format of HP manufacturer.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
