Planet SGS-6341-24T4X User Manual

28-67
Using standard method.
User Guide:
After configure this command, if users do not configure circuit-id on interface, it will create circuit-id
suboption for option82 according to self-defined method. Self-defined format of circuit-id: if
self-defined format is ascii, the filled format of vlan such as “Vlan2”, the format of port such as
“Ethernet1/0/1”, the format of mac and remote-mac such as “00-02-d1-2e-3a-0d”. If self-defined
format is hex, the filled format of vlan occupies 2 bytes, port occupies 4 bytes, a byte means slot (for
chassis switch, it means slot ID, for box switch, it is 1), a byte means Module (the default is 0), two
bytes means port ID beginning from 1, mac and remote-mac occupy 6 bytes. Each option will be
filled to packets according to the configured order of the commands and divide them with delimiter
(delimiter is ip dhcp relay information option delimiter configuration).
Example:
Set self-defined method of circuit-id suboption as port, mac for option82.
Switch(config)# ip dhcp relay information option self-defined subscriber-id port id switch-id mac
28.9 ip dhcp relay information option self-defined
subscriber-id format
Command:
ip dhcp relay information option self-defined subscriber-id format [ascii | hex]
Function:
Set self-defined format of circuit-id for relay option82.
Command Mode:
Global Mode
Default:
ascii.
User Guide:
self-defined format use ip dhcp relay information option type self-defined subscriber-id to create
circuit-id format.
Example:
Set self-defined format of circuit-id as hex for relay option82.
Switch(config)# ip dhcp relay information option self-defined subscriber-id format hex

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
