Planet SGS-6341-24T4X User Manual

45-65
Command:
ipv6 mld version <version_no>
no ipv6 mld version
Function:
Configure the version of the MLD protocol running on the interface; the “no ipv6 mld version”
command restores the manually configured version to the default one.
Parameter:
<version_no> is the version number of the MLD protocol, with a valid range of 1-2.
Default:
2 by default
Command Mode:
Interface Configuration Mode
Usage Guide:
While there is routers still not upgraded to version 2 of MLD protocol on the subnet connected, the
interface should be configured to corresponding version.
Example:
Configure the MLD version to 2.
Swith(config)#interface vlan 1
Swith(config-if-vlan1)#ipv6 mld version 2
45.7.15 show ipv6 mld groups
Command:
show ipv6 mld groups [{<ifname | group_addr>}]
Function:
Display the MLD group information.
Parameter:
<ifname> is the name of the interface. Display the MLD group information. <group_addr> is the
group address. Display the specified group information.
Default:
Do not display
Command Mode:
Admin Mode
Example:
Switch#sh ipv6 mld group
MLD Connected Group Membership
Group Address Interface Uptime Expires

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
