Planet SGS-6341-24T4X User Manual

33-141
<A.B.C.D/M> Clear the routes which match the destination address from the RIP route table.
specifies the IP address prefix and its length of the destination address
kernel delete kernel routes from the RIP route table
static delete static routes from the RIP route table
connected delete direct routes from the RIP route table
rip only delete RIP routes from the RIP route table
ospf only delete OSPF routes from the RIP route table
isis only delete ISIS routes from the RIP route table
bgp only delete BGP routes from the RIP route table
all delete all routes from the RIP route table
Default:
No default configurations.
Command Mode:
Admin mode
Usage Guide:
Use this command with the all parameter will delete all learnt route in the RIP route which will be
immediately recovered except for rip route. The dynamic learnt RIP route can only be recovered by
studying one more time.
Example:
Switch# clear ip rip route 10.0.0.0/8
Switch# clear ip rip route ospf
33.4 debug rip
Command:
debug rip [events| nsm| packet[recv|send][detail]| all]
no debug rip [events| nsm| packet[recv|send][detail]| all]
Function:
Open various RIP adjustment switches and show various adjustment debugging messages. The
“no debug rip [events| nsm| packet[recv|send][detail]| all]” command close corresponding
debugging switch.
Parameter:
events shows the debugging messages of RIP events
nsm shows the communication messages between RIP and NSM
packet shows the debugging messages of RIP data packets
recv shows the messages of the received data packets
send shows the messages of the sent data packets

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
