Planet SGS-6341-24T4X User Manual

33-142
detail shows the messages of received or sent data packets
Default: Debug switch closed.
Command Mode:
Admin mode and global mode
Example:
Switch# debug rip packet
Switch#1970/01/01 01:01:43 IMI: SEND[Vlan1]: Send to 224.0.0.9:520
1970/01/01 01:01:43 IMI: SEND[Vlan1]: Send to 224.0.0.9:520
1970/01/01 01:01:47 IMI: RECV[Vlan1]: Receive from 20.1.1.2:520
33.5 debug rip redistribute message send
Command:
debug rip redistribute message send
no debug rip redistribute message send
Function:
To enable the debugging of sending messages for routing redistribution messages from OSPF
process or BGP protocol for RIP. The no form of this command will disable the debugging
messages.
Default:
Close the debug by default.
Command Mode:
Admin Mode.
Example:
Switch#debug rip redistribute message send
Switch#no debug rip redistribute message send
33.6 debug rip redistribute route receive
Command:
debug rip redistribute route receive
no debug rip redistribute route receive
Function:
To enable debugging of received messages from NSM for RIP. The no form of this command will
disable debugging of received messages from NSM for RIP.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
