Planet SGS-6341-24T4X User Manual

35-201
35.24 filter-policy
Command:
filter-policy <access-list-name>
no filter-policy
Function:
Use access list to filter the route obtained by OSPF, the no command cancels the route filtering.
Parameter:
<access-list-name>: Access list name will be applied, it can use numeric standard IP access list
and naming standard IP access list to configure.
Default:
There is no default configuration.
Command Mode:
OSPF protocol mode
Usage Guide:
This command is used to filter the route obtained by OSPF. Do not filter any routes when the
specified access list is not exist, for the routes which do not match permit rule of access list, they will
be filtered. One access list can be set for this command, only the last configuration takes effect
when configuring many times.
Example:
Use access list 1 to filter the routes which do not belong to 172.10.0.0/16 segment.
Switch#config terminal
Switch(config)#access-list 1 permit 172.10.0.0 0.0.255.255
Switch(config)#router ospf
Switch(config-router)#filter-policy 1
35.25 host area
Command:
host <host-address> area <area-id> [cost <cost>]
no host <host-address> area <area-id> [cost <cost>]
Function:
Use this command to set a stub host entire belongs to certain area. The “[no] host
<host-address> area <area-id> [cost <cost>]” command cancels this configuration.
Parameter:
<host-address> is host IP address show in dotted decimal notation.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
