Planet SGS-6341-24T4X User Manual

34-171
Parameter:
<access-list-name> is the name or access-list number to be applied.
<prefix-list-name> is the name of the prefix-list to be applied.
<ifname> specifies the name of interface to be applied with route filtering.
Default:
Function disabled by RIPng by default.
Command Mode:
Router mode
Usage Guide:
The filter will be applied to all interfaces if no specific interface is set.
Example:
Switch#config terminal
Switch(config)#router ipv6 rip
Switch(config-router)#distribute-list prefix myfilter in Vlan1
34.6 debug ipv6 rip
Command:
debug ipv6 rip [events| nsm| packet [recv|send][detail]| all]
no debug ipv6 rip [events| nsm| packet [recv|send][detail]| all]
Function:
For opening various debugging switches of RIPng, showing various debugging messages. The “no
debug ipv6 rip [events| nsm| packet [recv|send][detail]| all]” command close the corresponding
debugging switch.
Parameter:
events shows the debugging message of RIPng events
nsm shows the communication messages between RIPng and NSM.
packet shows the debugging messages of RIPng data packets
recv shows the messages of the received data packets
send shows the messages of the sent data packets
detail shows the messages of the data packets received or sent.
Default:
Not enabled
Command Mode:
Admin mode
Example:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
