Planet SGS-6341-24T4X User Manual

14-110
spanning-tree mst configuration” restores the attributes of the MSTP to their default values.
Command mode:
Global Mode
Default:
The default values of the attributes of the MSTP region are listed as below:
Attribute of MSTP
Default Value
Instance There is only the instance 0. All the VLANs (1~4094) are mapped
to the instance 0.
Name
MAC address of the bridge
Revision
0
Usage Guide:
Whether the switch is in the MSTP region mode or not, users can enter the MSTP mode, configure
the attributes, and save the configuration. When the switch is running in the MSTP mode, the
system will generate the MST configuration identifier according to the MSTP configuration. Only if
the switches with the same MST configuration identifier are considered as in the same MSTP
region.
Example:
Enter MSTP region mode.
Switch(config)#spanning-tree mst configuration
Switch(Config-Mstp-Region)#
14.1.20 spanning-tree mst cost
Command:
spanning-tree mst <instance-id> cost <cost>
no spanning-tree mst <instance-id> cost
Function:
Sets path cost of the current port in the specified instance; the command “no spanning-tree mst
<instance-id> cost” restores the default setting.
Parameter:
<instance-id> sets the instance ID. The valid range is from 0 to 48. <cost> sets path cost. The
valid range is from 1 to 200,000,000.
Command mode:
Port Mode
Default:
By default, the port cost is relevant to the port bandwidth.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
