Planet SGS-6341-24T4X User Manual

45-64
Example:
Configure the interface’s timeout of MLD queries to 100s.
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ipv6 mld query-timeout 100
45.7.13 ipv6 mld static-group
Command:
ipv6 mld static-group <group_address> [source <source_address>]
no ipv6 mld static-group <group_address> [source <source_address>]
Function:
Configure certain static group or static source on the interface. The “no” form of this command
cancels certain previously configured static group or static source.
Parameter:
<group_address> is a valid IPv6 multicast address;<source_address> is a valid IPv6 unicast
address.
Default:
No static group or static source is configured on the interface by factory default.
Command Mode:
Interface Configuration Mode
Usage Guide:
The valid range of the static group multicast address configured by the interface is the dynamic
multicast address specified by the IPv6 protocol. Once the interface configures static group or
static source for the multicast address, no matter whether there is membership qualification report
of this group or source in the subnet, MLD protocol will consider that the group or source exist. Note:
the configured static source is the source to be forwarded.
Example:
Configure an MLD static-group ff1e::1:3 on interface vlan2.
Switch(config)#interface vlan 2
Switch(Config-if-Vlan2)#ipv6 mld static-group ff1e::1:3
Configure a static source 2001::1 of the group ff1e::1:3 on interface vlan2
Switch(config)#int vlan2
Switch(Config-if-Vlan2)#ipv6 mld static-group ff1e::1:3 source 2001::1
45.7.14 ipv6 mld version

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
