Planet SGS-6341-24T4X User Manual

45-63
Configure the maximum of the response time of MLD queries; the “no ipv6 mld query-
max-response-time” command restores the default value.
Parameter:
<time_val> is the maximum of the response time of MLD queries, it ranges from 1 to 25s.
Default:
10s.
Command Mode:
Interface Configuration Mode
Usage Guide:
When the switch receives a query message, the host will set a timer to each multicast group. The
timer’s value is between 0 to the maximum response time. When any one of the timers decreases to
0, the host will group member announce messages. Configuring the maximum response time
reasonablely, the host can swiftly response to the query messages and the router can also get the
group members’ existing states quickly.
Example:
Configure the maximum response time of MLD queries to 20s.
Switch (config)#interface vlan 1
Switch(Config-if-Vlan1)#ipv6 mld query- max-response-time 20
45.7.12 ipv6 mld query-timeout
Command:
ipv6 mld query-timeout <time_val>
no ipv6 mld query-timeout
Function:
Configure the interface’s timeout of MLD queries; the “no ipv6 mld query-timeout” command
restores the default value.
Parameter:
<time_val> is the timeout of MLD queries, it ranges from 60 to 300s
Default:
255s
Command Mode:
Interface Configuration Mode
Usage Guide:
In the share network, when there are more switches that run MLD, one switch will be selected as
the querying host and others set a timer to inspect the querying host’s state. If no querying packet is
received when the timeout is over, a switch will be reselected as the querying host.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
