SGS-6341 Series Command Guide
1-74
login:123
password:***
XGS3>
1.2.10 telnet server enable
Command:
telnet server enable
no telnet server enable
Function:
Enable the Telnet server function in the switch: the “no telnet server enable” command disables the Telnet function in
the switch.
Default:
Telnet server function is enabled by default.
Command mode:
Global Mode
Usage Guide:
This command is available in Console only. The administrator can use this command to enable or disable the Telnet
client to login to the switch.
Example:
Disable the Telnet server function in the switch.
Switch(config)#no telnet server enable
1.2.11 telnet-server max-connection
Command:
telnet-server max-connection {<max-connection-number> | default}
Function:
Configure the max connection number supported by the Telnet service of the switch.
Parameters:
<max-connection-number>: the max connection number supported by the Telnet service, ranging from 5 to 16.
The default option will restore the default configuration.
Default:
The system default value of the max connection number is 5.
Command Mode:
Global Mode
Usage Guide:

Table of Contents

Other manuals for Planet SGS-6341-24T4X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet SGS-6341-24T4X and is the answer not in the manual?

Planet SGS-6341-24T4X Specifications

General IconGeneral
Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Form factor1U
CertificationFCC Part 15 Class A, CE
Product colorBlack
Console portRJ-45
SFP+ module slots quantity4
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity24
Routing entries128
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN featuresStacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Flash memory16 MB
Internal memory512 MB
Processor frequency400 MHz
AuthenticationMAC-based authentication, Port-based authentication
Security algorithmsSNMPv3, SSH, SSL/TLS
Throughput95.24 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power supply included-
Power consumption (max)19.9 W
Heat dissipation67.91 BTU/h
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)5 - 90 %
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width440 mm
Height43.6 mm
Weight3170 g
