Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
1-96
1.4.22 snmp-server view
Command:
snmp-server view <view-string> <oid-string> {include | exclude}
no snmp-server view <view-string> [ <oid-string> ]
Function:
This command is used to create or renew the view information; the “no" form of this command deletes the view
information.
Command Mode:
Global Mode.
Parameter:
<view-string> view name, containing 1-32 characters.
<oid-string>is OID number or corresponding node name, containing 1-255 characters.
include | exclude, include/exclude this OID.
Usage Guide:
The command supports not only the input using the character string of the variable OID as parameter. But also
supports the input using the node name of the parameter.
Example:
Create a view, the name is readview, including iso node but not including the iso.3 node
Switch (config)#snmp-server view readview iso include
Switch (config)#snmp-server view readview iso.3 exclude
Delete the view
Switch (config)#no snmp-server view readview
1.5 Commands for Switch Upgrade
1.5.1 copy
（
FTP
）
Command:
copy <source-url> <destination-url> [ascii | binary]
Function:
Download files to the FTP client.
Parameter:
<source-url> is the location of the source files or directories to be copied;
<destination-url> is the destination address to which the files or directories to be copied; forms of <source-url> and

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
