SGS-6341 Series Command Guide
1-97
<destination-url> vary depending on different locations of the files or directories.
ascii indicates the ASCII standard will be adopted;
binary indicates that the binary system will be adopted in the file transmission（default transmission method）.When
URL represents an FTP address, its form should be:
ftp://<username>:<password>@{<ipaddress>|<ipv6address>|<hostname> }/<filename>,amongst <username> is the
FTP user name,<password> is the FTP user password,<ipaddress>|<ipv6address> is the IPv4 or IPv6 address of
the FTP server/client,<hostname> is the name of the host mapping with the IPv6 address,it does not support the file
download and upload with hosts mapping with IPv4 addresses,<filename> is the name of the FTP upload/download
file.
Special keywords of the filename
Keywords
Source or destination addresses
running-config
Running configuration files
startup-config
Startup configuration files
nos.img
System files
nos.rom
System startup files
Command Mode:
Admin Mode.
Usage Guide:
This command supports command line hints, namely if the user can enter commands in following forms: copy
<filename> ftp:// or copy ftp:// <filename> and press Enter, following hints will be provided by the system：
ftp server ip/ipv6 address [x.x.x.x]/[x:x::x:x] >
ftp username>
ftp password>
ftp filename>
Requesting for FTP server address, user name, password and file name
Examples:
(1) Save images in the FLASH to the FTP server of 10.1.1.1, FTP server username is Switch, password is superuser
Switch#copy nos.img ftp://Switch:superuser@10.1.1.1/nos.img
(2) Obtain system file nos.img from the FTP server 10.1.1.1, the username is Switch, password is superuser
Switch#copy ftp://Switch:superuser@10.1.1.1/nos.img nos.img
(3) Save images in the FLASH to the FTP server of 2004:1:2:3::6
Switch#copy nos.img ftp://username:password@2004:1:2:3::6/ nos.img
(4) Obtain system file nos.img from the FTP server 2004:1:2:3::6
Switch#copy ftp:// username:password@2004:1:2:3::6/nos.img nos.img
(5) Save the running configuration files
Switch#copy running-config startup-config

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
