Planet SGS-6341-24T4X User Manual

12-70
VLANs.
Parameter:
WORD is the VLAN ID to be created/deleted, valid range is 1 to 4094, connect with ';' and '-'.
Command mode:
Global Mode.
Default:
Only VLAN1 is set by default.
Usage Guide:
VLAN1 is the default VLAN and cannot be configured or deleted by the user. The maximal VLAN
number is 4094. It should be noted that dynamic VLANs learnt by GVRP cannot be deleted by this
command.
Example:
Create VLAN100 and enter the configuration mode for VLAN 100.
Switch(config)#vlan 100
Switch(Config-Vlan100)#
12.1.35 vlan internal
Command:
vlan <2-4094> internal
Function:
Specify the internal VLAN ID. After an ID is specified as the internal VLAN ID, it is not allowed to be
used by other VLAN. Internal VLAN is only used to LOOPBACK interface and can not add physical
port. New internal VLAN ID takes effect after save the configuration and reboot the switch.
Parameter:
<vlan-id>: The ID is specified as internal VLAN ID, the range is 2 to 4094.
Command mode:
Global Mode.
Default:
1006.
Usage Guide:
Set 1006 as the default internal VLAN ID, the internal VLAN ID needs to be modified when the
network set 1006 as VLAN ID. Internal VLAN ID must select an unused ID or else affect other VLAN.
This command takes effect after save the configuration and reboot the switch.
Example:
Set 100 as the internal VLAN ID.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
