Planet SGS-6341-24T4X User Manual

14-114
Example:
Enable rootguard function for port 1/0/2 in instance 0.
Switch(config)#interface ethernet 1/0/2
Switch(Config-If-Ethernet1/0/2)#spanning-tree mst 0 rootguard
Switch(Config-If-Ethernet1/0/2)#
14.1.25 spanning-tree portfast
Command:
spanning-tree portfast [bpdufilter | bpduguard] [recovery <30-3600>]
no spanning-tree portfast
Function:
Set the current port as boundary port, and BPDU filter、BPDU guard as specified mode or default
mode ; the command “no spanning-tree portfast” sets the current port as non-boundary port.
Parameter:
bpdufilter: configure the border port mode as BPDU filter
bpduguard: configure the border port mode as BPDU guard
recovery: configure the border port can be recovered automatically after implement bpduguard
violation operation
<30-3600>: the recovery time, do not recover it by default
Command mode:
Port Mode
Default:
All the ports are non-boundary ports by default when enabling MSTP.
Usage Guide:
When a port is set to be a boundary port, the port converts its status from discarding to forwarding
without bearing forward delay. Once the boundary port receives the BPDU, the port becomes a
non-boundary port.
Example:
Configure the border port mode as BPDU guard, the recovery time as 60s.
Switch(config)#interface ethernet 1/0/2
Switch(Config-If-Ethernet1/0/2)#spanning-tree portfast bpduguard recovery 60
Switch(Config-If-Ethernet1/0/2)#

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
