Planet SGS-6341-24T4X User Manual

72-11
by default.
Source IPv6 address
Source IPv6 address.
Repeat count[5]
Number of the ping packets.
Datagram size in byte[56] Packet
size of the ping command. 56 byte by
default.
Timeout in milli-seconds[2000] Timeout for ping command. 2 seconds by default.
Extended commands[n]
Extended configuration. Disabled by default.
! The network is reachable.
. The network is unreachable.
Success rate is 100 percent(8/8),
round-trip min/avg/max = 1/1/1ms
Statistic information, success rate is 100 percent of
ping packet.
72.9 show debugging
Command:
show debugging {bgp | dvmrp | igmp | ipv6 | mld | nsm | ospf | other | pim | rip | spanning-tree
| vrrp}
Function:
Display the debug switch status.
Usage Guide:
If the user needs to check what debug switches have been enabled, show debugging command
can be executed.
Command mode:
Admin Mode
Example:
Check for currently enabled debug switch.
Switch#show debugging ospf
OSPF debugging status:
OSPF all IFSM debugging is on
OSPF packet Hello detail debugging is on
OSPF packet Database Description detail debugging is on
OSPF packet Link State Request detail debugging is on
OSPF packet Link State Update detail debugging is on
OSPF packet Link State Acknowledgment detail debugging is on
OSPF all LSA debugging is on

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
