Planet SGS-6341-24T4X User Manual

35-209
point-to-multipoint: Set the OSPF network type to point-to-multipoint.
Default:
The default OSPF network type is broadcast.
Command Mode:
Interface Configuration Mode.
Example:
The configuration below set the OSPF network type of the interface vlan 1 to point-to-point.
Switch#config terminal
Switch(config)#interface vlan 1
Switch(Config-if-Vlan1)#ip ospf network point-to-point
35.37 ip ospf priority
Command:
ip ospf [<ip-address>] priority <priority>
no ip ospf [<ip-address>] priority
Function:
Configure the priority when electing “Defined layer 3 switch” at the interface. The “no ip ospf
[<ip-address>] priority” command restores the default value.
Parameter:
<ip-address> is the interface IP address show in dotted decimal notation.
<priority> is the priority of which the valid value ranges between 0～255.
Default:
The default priority when electing DR is 1.
Command Mode:
Interface Configuration Mode.
Usage Guide:
When two layer 3 switches connected to the same segments both want to be the “Defined layer 3
switch”, the priority will decide which one should be chosen. Normally the one with higher priority
will be elected, or the one with larger router-id number if the priorities are the same. A layer 3 switch
with a priority equal to 0 will not be elected as “Defined layer 3 switch” or “Backup Defined layer 3
switch”.
Example:
Configure the priority of DR electing. Configure the interface vlan 1 to no election right, namely set
the priority to 0.
Switch#config terminal

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
