Planet SGS-6341-24T4X User Manual

35-210
Switch(config)#interface vlan 1
Switch(Config-if-Vlan1)#ip ospf priority 0
35.38 ip ospf retransmit-interval
Command:
ip ospf [<ip-address>] retransmit-interval <time>
no ip ospf [<ip-address>] retransmit-interval
Function:
Specify the retransmit interval of link state announcements between the interface and adjacent layer
3 switches. The “no ip ospf [<ip-address>] retransmit-interval” command restores the default
value.
Parameter:
<ip-address> is the interface IP address show in dotted decimal notation.
<time> is the retransmit interveral of link state announcements between the interface and adjacent
layer 3 switches, shown in seconds ang raning between 1～65535.
Default:
Default retransmit interval is 5 seconds.
Command Mode:
Interface Configuration Mode.
Usage Guide:
When a layer 3 switch transmits LSA to its neighbor, it will maintain the link state announcements till
confirm from the object side is received. If the confirm packet is not received within the interval, the
LSA will be retransmitted. The retransmit interval must be larger than the time it takes to make a
round between two layer 3 switches.
Example:
Configure the LSA retransmit interval of interface vlan 1 to 10 seconds.
Switch#config terminal
Switch(config)#interface vlan 1
Switch(Config-if-Vlan1)#ip ospf retransmit-interval 10
35.39 ip ospf transmit-delay
Command:
ip ospf [<ip-address>] transmit-delay <time>

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
