SGS-6341 Series Command Guide
6-147
Disable the function of detecting the loopbacks through the port.
Command Mode:
Port Mode.
Usage Guide:
If a port can be a TRUNK port of multiple Vlans, the detection of loopbacks can be implemented on the basis of
port+Vlan, which means the objects of the detection can be the specified Vlans on a port. If the port is an ACCESS
port, only one Vlan on the port is allowed to be checked despite the fact that multiple Vlans can be configured. This
function is not supported under Port-channel.
Examples:
Enable the function of loopback detection under port 1/0/2 mode.
Switch(config)#interface ethernet 1/0/2
Switch(Config-If-Ethernet1/0/2)#switchport mode trunk
Switch(Config-If-Ethernet1/0/2)#switchport trunk allowed vlan all
Switch(Config-If-Ethernet1/0/2)#loopback-detection specified-vlan 1;3;5-20
Switch(Config-If-Ethernet1/0/2)#no loopback-detection specified-vlan 1;3;5-20
6.6 show loopback-detection
Command:
show loopback-detection [interface <interface-list>]
Function:
Display the state of loopback detection on all ports if no parameter is provided, or the state and result of the specified
ports according to the parameters.
Parameters:
<interface-list> the list of ports to be displayed, for example: ethernet 1/0/1.
Command Mode:
Admin and Configuration Mode.
Usage Guide:
Display the state and result of loopback detection on ports with this command.
Example:
Display the state of loopback detection on port 4.
Switch(config)#show loopback-detection interface Ethernet 1/0/4
loopback detection config and state information in the switch!
PortName Loopback Detection Control Mode Is Controlled
Ethernet1/0/4 Enable Shutdown No

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
