Planet SGS-6341-24T4X User Manual

11-37
Normal forwarding will be suspended during the remote-
loopback, are you sure to support
remote-loopback? [Y/N]
11.25 ethernet-oam timeout
Command:
ethernet-oam timeout <seconds>
no ethernet-oam timeout
Function:
Configure the timeout of OAM connection, no command restores the default value.
Parameter:
<seconds>, the timeout ranging from 5 to 10 seconds.
Default:
5s.
Command Mode:
Port mode
Usage Guide:
OAM connection will be disconnected if no OAMPDU is received after specified timeout.
Example:
Set the timeout of OAM connection for ethernet 1/0/4 to 6 seconds.
Switch(Config-If-Ethernet1/0/4)#ethernet-oam timeout 6
11.26 show ethernet-oam
Command:
show ethernet-oam [{local | remote} interface {ethernet |} <IFNAME>]
Function:
Show Ethernet OAM connection of specified or all ports.
Parameter:
Overview information of all Ethernet OAM connections will be shown if no parameters is input
local, show detailed information of local OAM connection
remote, show detailed information of remote OAM connection
<IFNAME>, the port that OAM connection information will be shown
Command Mode:
Admin mode

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
