Planet SGS-6341-24T4X User Manual

11-38
Example:
Show overview information of Ethernet OAM connection.
Switch#show ethernet-oam
Remote-Capability codes: L - Link Monitor, R - Remote Loopback
U - Unidirection, V - Variable Retrieval
-----------------------------------------------------------------------------------------------------------------
Interface Local-Mode Local-Capability Remote-MAC-Addr Remote-Mode Remote-Capability
1/0/1 active L R 0030.4f02.2e5d active L R
1/0/2 active L R 0030.4f19.3a3e avtive L R
1/0/4 active L R 0030.4f26.480c passive L R
1/0/5 active L R 0030.4f28.020a active L R
Field
Description
Interface
port with Ethernet OAM enabled
Local-Mode
Working mode of the local port OAM.
Local-Capability
Functions are supported by local port OAM
L - Link Monitor, R - Remote Loopback
U - Unidirection, V - Variable Retrieval
Remote-MAC-Addr
MAC address of the peer
Remote-Mode
OAM working mode of the peer
Remote-Capability
Functions are supported by OAM of the peer
L - Link Monitor, R - Remote Loopback
U - Unidirection, V - Variable Retrieval
Show detailed information of local OAM entity for ethernet 1/0/2:
Switch#show ethernet-oam local interface ethernet1/0/2
Ethernet1/0/2 oam local Information：
oam_status=enable
local _mode=active
period=1s
timeout=8s
Loopback Supported=YES
Unidirectional Support=YES
Link Events=YES
Remote Failure=YES
local_pdu=INFO
local_mux_action=FWD

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
