Planet SGS-6341-24T4X User Manual

31-121
among nodes is identified by sequence-number. “permit” means the node filter will be passed if all
match subs are obtained by current route and then further all the set sub of this node will be
executed without entering the check in the next node; if the match subs can not be met, the proceed
to the check in next node. Relation among different node should be “or”, namely one node check
passed then the route filter is passed when the switch checks each node in turn in the route-map.
Attentions should be paid on that at least one node match mode should be “permit” when more than
one node is defined. When a route-map is used for filtering routing messages, if certain routing
message can not pass any node check, then it is considered denied by the route-map. If all nodes in
the route-map are set to deny mode, then all routing message should not be able to pass that
route-map.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#match as-path 60
Switch(config-route-map)#set weight 30
31.15 set aggregator
Command:
set aggregator as <as-number> <ip_addr>
no set aggregator as [<as-number> <ip_addr>]
Function:
Assign an AS number for BGP aggregator. The “no set aggregator as [<as-number> <ip_addr>]”
deletes this configuration.
Parameter:
<as-number > is the AS number, <ip_addr> is the ip address of the aggregator shown in decimal
notation.
Command Mode:
route-map mode
Usage Guide:
To use this command, one match clause should at first be defined.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#set aggregator as 200 10.1.1.1

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
