Planet SGS-6341-24T4X User Manual

31-122
31.16 set as-path
Command:
set as-path prepend <as-num>
no set as-path prepend [<as-num>]
Function:
Add AS numbers in the AS path domain of the BGP routing message. The “no set as-path
prepend [<as-num>]” command deletes this configuration.
Parameter:
<as-num > is the AS number, circulating inputting several numbers is available.
Command Mode:
route-map mode
Usage Guide:
To add AS number in the As domain of the BGP, the AS path length should be lengthened so to
affect the best neighbor path option. To use this command, one match clause should at first be
defined.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#set as-path prepend 200 100.100
31.17 set atomic-aggregate
Command:
set atomic-aggregate
no set atomic-aggregate
Function:
Configure the atomic aggregate attributes. The “no set atomic-aggregate” command deletes this
configuration.
Command Mode:
route-map mode
Usage Guide:
The BGP informs other BGP speaker by the atomic aggregate attributes. Local system selects a
sub-specified route other than the more specified routes included in it. To use this command, one
match clause should at first be defined.
Example:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
