Planet SGS-6341-24T4X User Manual

26-21
Command mode:
Admin Mode.
Usage Guide:
“show ip dhcp binding” command can be used to view binding information for IP addresses and
corresponding DHCP client hardware addresses. If the DHCP server is informed that a DHCP client
is not using the assigned IP address for some reason before the lease period expires, the DHCP
server would not remove the binding information automatically. The system administrator can use
this command to delete that IP address-client hardware address binding manually, if “all” is
specified, then all auto binding records will be deleted, thus all addresses in the DHCP address pool
will be reallocated.
Example:
Removing all IP-hardware address binding records.
Switch#clear ip dhcp binding all
Related Command:
show ip dhcp binding
26.1.3 clear ip dhcp conflict
Command:
clear ip dhcp conflict {<address> | all }
Function:
Deletes an address present in the address conflict log.
Parameters:
<address> is the IP address that has a conflict record;
all stands for all addresses that have conflict records.
Command mode:
Admin Mode.
Usage Guide:
“show ip dhcp conflict” command can be used to check which IP addresses are conflicting for use.
The “clear ip dhcp conflict” command can be used to delete the conflict record for an address. If
"all” is specified, then all conflict records in the log will be removed. When records are removed from
the log, the addresses are available for allocation by the DHCP server.
Example:
The network administrator finds 10.1.128.160 that has a conflict record in the log and is no longer
used by anyone, so he deletes the record from the address conflict log.
Switch#clear ip dhcp conflict 10.1.128.160

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
